1 - 4 MC3090Z RFID Mobile Computer Integrator Guide
The MC3090Z RFID mobile computer provides a wide range of features that enable implementation of complete,
high-performance, intelligent RFID solutions.
MC3090Z RFID Mobile Computer Parts
Figure 1-3 MC3090Z RFID Mobile Computer Parts
NOTE The MC3090Z RFID mobile computer supports a 2x battery only; do not use a 1x battery.
The Four-Slot Cradle does not accommodate the MC3090Z RFID mobile computer.
Due to component tolerances, some users may experience undesired behavior when using battery part number
55-060112-xx. If the unit turns off without proper warning messages during heavy use, use battery 55-002152-xx
(p/n 82-127909-xx).
Keypad
RFID Module
Display
Power
Scan Button
Beeper
Trigger
Scan LED
Indicators
(red/green)
Charge LED
Indicator
(amber)
Scan LED Indicator
(red/green)
