A - 2 MC55A0/MC55N0 Enterprise Digital Assistant User Guide
Network Connections Full-speed USB, host or client, Bluetooth and WiFi.
USB host mode available with appropriate cables only.
Notification LED and audible alert
Keypad Options 26-key numeric; 44-key QWERTY, 44-key AZERTY, 44-key QWERTZ;
PIM (available on the MC55N0 in a future release)
Audio Speaker, microphone, receiver (for handset mode use), and Bluetooth
audio headsets.
Performance Characteristics
CPU Marvell PXA 320 processor at 806 MHz
Operating System
Microsoft
®
Windows Mobile™ 6.5.3 Classic
Memory 256 MB RAM/1 GB Flash
Interface/Communications USB 1.1 Full-speed
Output Power USB: 5 VDC @ 500 mA max.
User Environment
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 32°F to 104°F / 0° C to 40° C
Humidity 95% non-condensing
Drop Specification Multiple 1.8 m (6 ft.) drops per MIL-STD 810G specifications.
Tumble 1000 0.5 m (1.6 ft.) tumbles (2000 drops) per IEC tumble specifications
Electrostatic Discharge (ESD) +/-15kVdc air discharge, +/-8kVdc direct discharge, +/-8kVdc indirect
discharge
Sealing IP64 per IEC sealing specifications
Wireless LAN Data and Voice Communications
Wireless Local Area Network
(WLAN) radio
MC55A0: Tri-mode IEEE
®
802.11a/b/g
MC55N0: Quad-mode IEEE
®
802.11a/b/g/n
Data Rates Supported 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
Operating Channels Chan 8 - 165 (5040 - 5825 MHz), Chan 1 - 13 (2412 - 2472 MHz), Chan 14
(2484 MHz) Japan only; actual operating channels/frequencies depend on
regulatory rules and certification agency.
Table A-1
MC55 Technical Specifications (Continued)
Item Description
