PIM Keypad Configuration
The PIM keypad contains application keys and scroll keys. Note that an application can change keypad
functions so the MC55’s keypad may not function exactly as described. See Table B-1 for key and button
descriptions and Table B-2 on page B-4 for the keypad’s special functions.
Figure B-5 MC55 PIM Keypad
NOTE Available on the MC55N0 in a future release
