Motorola MC55A0 User Manual

B - 6 MC55A0/MC55N0 Enterprise Digital Assistant User Guide
Figure B-4 QWERTZ Keypad Configuration
Table B-3 Alpha-numeric Keypad Descriptions
Key Action
Blue Key Press and release the Blue key once to activate this mode temporarily, followed by
another key. This displays the following icon at the bottom of the screen, until a
second key is pressed:
Press and release the Blue key twice to lock this mode. This displays the following
icon at the bottom of the screen:
Press and release the Blue key a third time to unlock.
Orange Key Accesses the secondary layer of characters and actions (shown on the keypad in
orange).
Press and release the Orange key once to activate this mode temporarily, followed by
another key. This displays the following icon at the bottom of the screen, until a
second key is pressed:
Press and release the Orange key twice to lock this mode. This displays the following
icon at the bottom of the screen:
Press and release the Orange key a third time to unlock.
Talk/Start Menu Use this key in conjunction with the Blue key to instantly display the Start menu from
any application without tapping the screen. This function is user programmable.
To use a key as an application key (APP key) on the keyboard, create and install a
new keyboard remap table. However, to remap the green phone key as APP keys
through the registry, create an XML provisioning file that includes the following
entry:
<characteristic type=”HKLM\Hardware\DeviceMap\KYBD”>
<parm name=”GreenKeyOverride” value=”xx” datatype=”integer” />
[where xx is the new APP key code]
Provision the file to the MC55 to send an APP key code, instead of the original key
code, upon pressing the green phone key. Refer to the MC55A0/MC55N0
Integrator Guide for information on creating XML provisioning files.
ok

Motorola MC55A0 Specifications

General

Brand	Motorola
Model	MC55A0
Category	PDA
Language	English
