Motorola MC55A0 User Manual

1 - 14 MC55A0/MC55N0 Enterprise Digital Assistant User Guide
Figure 1-14 Feed Handstrap into Handstrap Slot
2. Slide the pin into the bottom of the handstrap.
3. Center the pin in the handstrap loop.
4. Pull the handstrap so that the pin and bottom of the handstrap slide into position in the mounting area.
Figure 1-15 Pin and Handstrap in Mounting Area
5. Replace the battery.
6. Replace the stylus tether onto the handstrap.
Figure 1-16 Slide Handstrap and Tether Over Handstrap Mount
7. Insert the handstrap clip into the slot on the MC55. Ensure that it is securely in place.
NOTE Handstrap and pin should fit securely into the handstrap mounting area. When pulling on handstrap use
enough force to engage pin into place.

Motorola MC55A0 Specifications

General

Brand	Motorola
Model	MC55A0
Category	PDA
Language	English
