5.8.5
Ethernet Cables
Figure 69: Mobile to Control Head Ethernet Cable Pin Diagram
Figure 70: Mobile to Mobile Ethernet Cable Pin Diagram
CONNECTION
BRICK 1
TX+
TX-
RX+
RX-
GND
GND
CH ON OFF OUT
CH ON OFF IN
P1
2
3
4
7
5
6
8
9
P2
4
7
2
3
5
6
9
8
COLOR
GREEN
GREEN / WHITE
BLUE
BLUE / WHITE
BLACK
BROWN
ORANGE
GRA
Y
DRAIN
BRICK 2
RX+
RX-
TX+
TX-
GND
GND
CH ON OFF IN
CH ON OFF OUT
SHIELD
SHIELD
5.8.6
Remote Ethernet Control Head Y-Cable (Accessories Expansion
Cable)
Part Number: PMKN4133_
68015000181-LB
Chapter 5: Connectors and PIN Assignment
