Postrequisites: See the following table for power cables available for this radio.
3.3.1
DC Power Cables
Table 42: DC Power Cables
Number Description Rating
GKN6270_ Power Cable to battery with fuse 10 A 12V Power Cable to Battery, Length: 3 m
GKN6274_ Power Cable to battery with fuse 10 A 12V Power Cable to Battery, Length: 6 m
6500139767 Fuse 10 A for Power Cable
6580283E02 Fuse 4 A for Ignition Sense Cable
6505663R02 Fuse 2 A for Y-Cable
CAUTION: In cases of blown fuses, replace only with fuses of identical value. Never insert ones
of different values.
NOTICE: For more information on ignition cables, see section “Installing Ignition Sense Cable”.
The Ignition Sense Cable allows the radio to be turned on and off by the vehicle ignition switch.
3.4
Installing Ignition Sense Cable
The PMKN4120_ Ignition Sense Cable allows the terminal to be turned on and off by the vehicle
ignition switch.
CAUTION: In cases of blown fuses, replace only with fuses of identical value. Never insert ones
of different values. Ensure that the fuse is removed during cable installation.
Procedure:
1 Plug the lead of the Ignition Sense Cable with the crimped on the terminal into #25 socket of the
accessory plug.
2 Route and secure the cable with the attached tie wrap.
3 Connect the other lead of the accessory cable to the ignition switch of the vehicle.
4 Insert the fuse into the fuse holder and close the cover.
68015000181-LB
Chapter 3: Vehicle Preparation
Send Feedback 43
