Motorola MT953C User Manual

Type No. Series Sales Model No. Short Description Model
NOTICE: Models 5500 M3 must select Telephone Style Control
Head – TSCH and/or Ethernet Control Head – eCH
WARNING: Ethernet Expansion Heads are only compatible with Ethernet Remote Heads. Do
not mix the Ethernet control head with non-Ethernet control heads. Also ensure use of the
proper Ethernet cables to connect Ethernet Expansion Head with TSCH, eCH, or another
Ethernet Expansion Head. If not connected properly, transceiver can be broken.
2.4
Model Specifications
Table 5: General Specifications
Parameter Value
Type Number MTM5200, MTM5400 350–390 MHz
MTM5x00 380–430 MHz
MTM5x00 410–470 MHz
MTM5x00 806–870 MHz
MT853C
MT953C
MT553C
MT753C
Temperature Range
for Transceiver
Operating -30 °C to +60 °C
Storage -40 °C to +85 °C
Power Supply Minimum: 10.8 Vdc
Nominal: 13.2 Vdc
Maximum: 15.6 Vdc
Max. Current Approx. 4.5 A
Dimensions (HxWxD)
in mm
Transceiver with Enhanced Control Head, Dash
Mount (MTM5200, MTM5400)
60 x 188 x 198
Dimensions (HxWxD)
in mm
Transceiver with Ethernet Expansion Head
(MTM5500)
45 x 170 x 190
Ethernet Control Head (eCH) 60 x 190 x 40
Telephone Style Control Head (TSCH) 220 x 65 x 75
Weight in grams: Transceiver with Enhanced Control Head, Dash
Mount (MTM5200, MTM5400)
1500
Weight in grams: Transceiver with Ethernet Expansion Head
(MTM5500)
1330
Ethernet Control Head (eCH) 310
Telephone Style Control Head (TSCH) (ex-
cludes cable)
450
GNSS Performance Autonomous Acquisition Sensitivity -146 dBm / -176 dBW
Tracking Sensitivity -160 dBm / -190 dBW
68015000181-LB
Chapter 2: Model Information and Accessories
26 Send Feedback
