ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-14
ioLogik E1242 Modbus Address and Register
Map
I/O
Parameter Name Description Start
Address
(decimal)
Point
Type
Start
Register
(decimal)
Length Access Type
AI_burnoutValue high/low word 0560 03:HOLDI
NG
REGISTER
40561 8 R/W 2 words
AI_mode 0: 0-10 V
1: 4-20mA
2: 0-20mA
4: 4-20mA
burnout
0544 03:HOLDI
NG
REGISTER
40545 4 R/W word
AI_rawValue 0512 04:INPUT
REGISTER
30513 4 R word
AI_rawValueMax 0532 04:INPUT
REGISTER
30533 4 R word
AI_rawValueMin 0528 04:INPUT
REGISTER
30529 4 R word
AI_resetMaxValue 1: reset max.
value
4153 01:COIL
STATUS
04154 4 R/W bit
AI_resetMinValue 1: reset min.
value
4145 01:COIL
STATUS
04146 4 R/W bit
AI_scaledValue high/low word 0520 04:INPUT
REGISTER
30521 8 R 2 words
AI_scaledValueMax high/low word 0546 04:INPUT
REGISTER
30547 8 R 2 words
AI_scaledValueMin high/low word 0536 04:INPUT
REGISTER
30537 8 R 2 words
AI_status 0: normal,
1: burnout,
2: over range,
3: under range
0576 04:INPUT
REGISTER
30577 4 R word
DI_counterOverflowFl
ag
0: Normal, 1:
Overflow
1000 02:INPUT
STATUS
11001 8 R bit
DI_counterOverflowFl
agClear
1: clear
overflow flag
0288 01:COIL
STATUS
00289 8 R/W bit
DI_counterReset 1: reset to
initial value
0272 01:COIL
STATUS
00273 8 R/W bit
DI_counterStatus 0: STOP, 1:
START
0256 01:COIL
STATUS
00257 8 R/W bit
DI_counterValue high/low word 0016 04:INPUT
REGISTER
30017 16 R 2 words
DI_status 0: OFF, 1: ON 0000 02:INPUT
STATUS
10001 8 R bit
DI-all_statusFromDI-
00
0: OFF, 1: ON 0048 04:INPUT
REGISTER
30049 1 R word
DO_p2pSafeModeFla
gClear
1: clear safe
mode flag
4128 01:COIL
STATUS
04129 4 R/W bit
