1. Introduction
The ioLogik E1200 industrial Ethernet remote I/O has two embedded Ethernet switch ports that allow
information to flow to another local Ethernet device or connect to the next ioLogik in a daisy-chain. Applications
such as factory automation, security and surveillance systems, and tunnel monitoring, can make use of
daisy-chained Ethernet for building multidrop I/O networks over standard Ethernet cables and familiar fieldbus
protocols. The daisy-chain function on the ioLogik E1200 Ethernet remote I/O not only increases the
connections between machines and panels, but it also lowers the cost of buying separate Ethernet switches,
and at the same time reduces labor fees and cabling by a large percentage. For example, if a production facility
contains 700 stations (20 points per station), the wiring cost reduction can reach 15% of the total
implementation cost.
The following topics are covered in this chapter:

Product Features

Inside the Box

Product Model Information

Product Specifications

Physical Dimensions

Hardware Reference
 Panel Guide
 Ethernet Port
 LED Indicators

I/O Circuit Diagram
 DI Circuit
 Sinking DO Circuit
 Sourcing DO Circuit
 DIO Circuit
 Relay Circuit
 AI Circuit
 RTD Circuit
 TC Circuit
