ioLogik E1200 Series EtherNet/IP Default Address Mappings
B-4
AO Channel Object (0x6C)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT class revision
0x64 0x01 GET aoIndex UINT AO - index
0x64 0x02 GET aoMode UINT AO - mode (0: 0-10 V, 1: 4-20 mA,
2: 0-20 mA)
0x64 0x03 SET aoValueRaw UINT AO - raw value
0x64 0x04 GET aoValueScaled REAL AO - scaled value
RTD Channel Object (0x6D)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT class revision
0x64 0x01 GET rtdIndex UINT RTD - index
0x64 0x02 GET rtdSensorType UINT RTD - sensor type
0x64 0x03 GET rtdValueEngineerin
gMultiplied
UINT RTD - Engineering Multiplied value
0x64 0x04 GET rtdValueScaled REAL RTD - scaled value
0x64 0x05 GET rtdValueEngineerin
gMultipliedMin
UINT RTD - minimum Engineering
Multiplied value
0x64 0x06 GET rtdValueEngineerin
gMultipliedMax
UINT RTD - maximum Engineering
Multiplied value
0x64 0x07 GET rtdValueScaledMin REAL RTD - minimum scaled value
0x64 0x08 GET rtdValueScaledMax REAL RTD - maximum scaled value
0x64 0x09 SET rtdResetMinValue BOOL RTD - reset minimum value (1:
RESET)
0x64 0x0A SET rtdResetMaxValue BOOL RTD - reset maximum value (1:
RESET)
TC Channel Object (0x6E)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT class revision
0x64 0x01 GET tcIndex UINT TC - index
0x64 0x02 GET tcSensorType UINT TC - sensor type
0x64 0x03 GET tcValueEngineering
Multiplied
UDINT TC - Engineering Multiplied value
0x64 0x04 GET tcValueScaled REAL TC - scaled value
0x64 0x05 GET tcValueEngineering
MultipliedMin
UDINT TC - minimum Engineering
Multiplied value
0x64 0x06 GET tcValueEngineering
MultipliedMax
UDINT TC – maximum Engineering
Multiplied value
0x64 0x07 GET tcValueScaledMin REAL TC - minimum scaled value
0x64 0x08 GET tcValueScaledMax REAL TC - maximum scaled value
0x64 0x09 SET tcResetMinValue BOOL TC - reset minimum value (1:
RESET)
0x64 0x0A SET tcResetMaxValue BOOL TC - reset maximum value (1:
RESET)
