ioLogik E1200 Series RESTful API Default Address Mappings
C-2
RESTful API Name Description Access
/api/slot/0/io/di/0/diCounterValue diCounterValue DI - Counter mode - value read-only
/api/slot/0/io/di/0/diCounterReset DI - Counter mode - reset
to initial value (1: RESET)
read-write
/api/slot/0/io/di/0/diCounterStatus DI - Counter mode - status
(0: STOP, 1: START)
read-write
/api/slot/0/io/do
/api/slot/0/io/do doIndex DO - index read-only
/api/slot/0/io/do doMode DO - mode (0: DO, 1:
Pulse)
read-only
/api/slot/0/io/do doStatus DO - DO mode - status (0:
OFF, 1: ON)
read-write
/api/slot/0/io/do doPulseCount DO - Pulse mode - count read-write
/api/slot/0/io/do doPulseOnWidth DO - Pulse mode -
ON width
(unit: 1 ms)
read-write
/api/slot/0/io/do doPulseOffWidth DO - Pulse mode - OFF
width (unit: 1 ms)
read-write
/api/slot/0/io/do doPulseStatus DO - Pulse mode - status
(0: STOP, 1: START)
read-write
/api/slot/0/io/do/0/doStatus doStatus DO - DO mode - status (0:
OFF, 1: ON)
read-write
/api/slot/0/io/do/0/doPulseCount doPulseCount DO - Pulse mode - count read-write
/api/slot/0/io/do/0/doPulseStatus doPulseStatus DO - Pulse mode - status
(0: STOP, 1: START)
read-write
/api/slot/0/io/relay
/api/slot/0/io/relay relayIndex Relay - index read-only
/api/slot/0/io/relay relayMode Relay - mode (0: Relay, 1:
Pulse)
read-only
/api/slot/0/io/relay relayStatus Relay - Relay mode -
status
(0: OFF, 1: ON)
read-write
/api/slot/0/io/relay relayTotalCount Relay - Relay mode - total
count
read-only
/api/slot/0/io/relay relayCurrentCount Relay - Relay mode -
current count
read-only
/api/slot/0/io/relay relayCurrentCountReset Relay - Relay mode - reset
current count (1: RESET)
read-write
/api/slot/0/io/relay relayPulseStatus Relay - Pulse mode -
status
(0: STOP, 1: START)
read-write
/api/slot/0/io/relay relayPulseCount Relay - Pulse mode - count read-write
/api/slot/0/io/relay relayPulseOnWidth Relay - Pulse mode - ON
width (unit: 1.5 s)
read-write
/api/slot/0/io/relay relayPulseOffWidth Relay - Pulse mode - OFF
width (unit: 1.5 s)
read-write
/api/slot/0/io/relay/0/relayStatus relayStatus Relay - Relay mode -
status
(0: OFF, 1: ON)
read-write
/api/slot/0/io/relay/0/relayPulseStatus relayPulseStatus Relay - Pulse mode -
status
(0: STOP, 1: START)
read-write
/api/slot/0/io/relay/0/relayPulseCount relayPulseCount Relay - Pulse mode - count read-write
/api/slot/0/io/ai
/api/slot/0/io/ai aiIndex AI - index read-only
/api/slot/0/io/ai aiMode AI - mode (0: 0-10 V, 1:
4-20mA, 2: 0-20mA, 4:
4-20mA burnout)
read-only

Moxa Technologies ioLogik E1260 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	660260 h
Certification	UL/cUL Class I Division 2, ATEX Zone 2
Product color	Silver
LED indicators	Yes
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.110 A
AC input voltage	24 V
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
