Moxa Technologies ioLogik E1260 User Manual

ioLogik E1200 Series Using the Web Console
3-28
RESTful API Setting
The ioLogik E1200 supports RESTful API. To enable this API, select the Enable Restful API checkbox.
EtherNet/IP Setting
The ioLogik E1200 supports the EtherNet/IP protocol. To enable the protocol, select the Enable Ethernet/IP
Protocol checkbox.
NOTE
The
EtherNet/IP function needs to be activated before it can be used. See Chapter 5 for details.
NOTE
The
ioLogik E1200 series only supports EtherNet/IP adapter mode. The maximum number of connections
allowed is
9 for read-only, and 1 for read/write.
System Management
Network Connection
TCP connections from other hosts appear on the Network Connection page. This information can assist you with
managing your devices.

Moxa Technologies ioLogik E1260 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	660260 h
Certification	UL/cUL Class I Division 2, ATEX Zone 2
Product color	Silver
LED indicators	Yes
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.110 A
AC input voltage	24 V
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
