ioLogik E1200 Series Introduction
1-2
Product Features
• Active communication with patented MX-AOPC UA Server
• 2-port Ethernet switch for daisy-chain topologies
• Easy mass deployment and configuration with ioSearch™utility
• User-friendly configuration via web browser
• Save time and wiring costs with peer-to-peer communication
• User-defined Modbus/TCP addressing
• Simplify I/O management with MXIO library on either Windows or Linux platform
• Wide operating temperature: -40 to 75°C (-40 to 167°F)
• Supports SNMPv1/v2c
• UL/cUL Class I Division 2, ATEX Zone 2 certification
Inside the Box
The ioLogik E1200 is shipped with the following items:
• ioLogik E1200 remote Ethernet I/O server
• Quick installation guide (printed)
NOTE
Notify your sales representative if any of the above items are missing or damaged.
Product Model Information
Model Description
ioLogik E1210 Remote Ethernet I/O with 2-port Ethernet switch and 16 DIs
ioLogik E1211 Remote Ethernet I/O with 2-port Ethernet switch and 16 DOs
ioLogik E1212
Remote Ethernet I/O with 2-port Ethernet switch, 8 DIs, and 8 DIOs
ioLogik E1213 Remote Ethernet I/O with 2-port Ethernet switch, 8 DIs, 4 DOs, and 4 DIOs (source type)
ioLogik E1214 Remote Ethernet I/O with 2-port Ethernet switch, 6 DIs, and 6 relays
ioLogik E1240 Remote Ethernet I/O with 2-port Ethernet switch and 8 AIs
ioLogik E1241 Remote Ethernet I/O with 2-port Ethernet switch and 4 AOs
ioLogik E1242 Remote Ethernet I/O with 2-port Ethernet switch and 4 AIs, 4DIs, and 4DIOs
ioLogik E1260 Remote Ethernet I/O with 2-port Ethernet switch and 6 RTDs
ioLogik E1262 Remote Ethernet I/O with 2-port Ethernet switch and 8 TCs
ioLogik E1210-T
Ethernet remote I/O with 2-port Ethernet switch and 16 DIs, -40 to 75°C operating
temperature
ioLogik E1211-T
Ethernet remote I/O with 2-port Ethernet switch and 16 DOs, -40 to 75°C operating
temperature
ioLogik E1212-T
Ethernet remote I/O with 2-port Ethernet switch, 8 DIs, and 8 DIOs, -40 to 75°C
operating temperature
ioLogik E1213-T
Remote Ethernet I/O with 2 Port Ethernet switch, 8 DIs, 4 DOs, and 4 DIOs (source
type), -40 to 75°C operating temperature
ioLogik E1214-T
Ethernet remote I/O with 2-port Ethernet switch, 6 DIs, and 6 Relays, -40 to 75°C
operating temperature
ioLogik E1240-T
Ethernet remote I/O with 2-port Ethernet switch and 8 AIs, -40 to 75°C operating
temperature
ioLogik E1241-T
Ethernet remote I/O with 2-port Ethernet switch and 4 AOs , -40 to 75°C operating
temperature
ioLogik E1242-T
Ethernet remote I/O with 2-port Ethernet switch, 4 AIs, 4 DIs, and 4 DIOs, -
40 to 75°C
operating temperature
ioLogik E1260-T
Ethernet remote I/O with 2-port Ethernet switch and 6 RTDs, -40 to 75°C operating
temperature
ioLogik E1262-T
Ethernet remote I/O with 2-port Ethernet switch and 8 TCs, -40 to 75°C operating
temperature

Moxa Technologies ioLogik E1260 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	660260 h
Certification	UL/cUL Class I Division 2, ATEX Zone 2
Product color	Silver
LED indicators	Yes
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.110 A
AC input voltage	24 V
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
