D
D. Network Port Numbers
ioLogik E1200 Network Port Usage
Port Type Usage
68 UDP BOOTP/DHCP
69 UDP Export/import configuration file
80
TCP
Web console service
161 UDP SNMP Agent
502 TCP Modbus/TCP communication
2222 UDP EtherNet/IP implicit message
4800 UDP Auto search
9020 TCP Peer-to-peer (default)
9200 TCP ioLogik 2500s expansion
10124 TCP Configuration port (ioSearch)
44818 TCP EtherNet/IP explicit message

Table of Contents

Other manuals for Moxa Technologies ioLogik E1260

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Moxa Technologies ioLogik E1260 and is the answer not in the manual?

Moxa Technologies ioLogik E1260 Specifications

General IconGeneral
TypeNetwork transmitter & receiver
Maximum transfer distance- m
Mean time between failures (MTBF)660260 h
CertificationUL/cUL Class I Division 2, ATEX Zone 2
Product colorSilver
LED indicatorsYes
Operating temperature (T-T)-40 - 167 °F
Cabling technology10/100Base-T(X)
Ethernet LAN (RJ-45) ports2
Input current0.110 A
AC input voltage24 V
Operating altitude0 - 2000 m
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth84 mm
Width27.8 mm
Height124 mm
Weight200 g
