ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-9
ioLogik E1214 Modbus Address and Register
Map
I/O
Parameter Name Description Start
Address
(decimal)
Point
Type
Start
Register
(decimal)
Length Access Type
DI_counterOverflowFl
ag
0: Normal, 1:
Overflow
1000 02:INPUT
STATUS
11001 6 R bit
DI_counterOverflowFl
agClear
1: clear
overflow flag
0288 01:COIL
STATUS
00289 6 R/W bit
DI_counterReset 1: reset to
initial value
0272 01:COIL
STATUS
00273 6 R/W bit
DI_counterStatus 0: STOP, 1:
START
0256 01:COIL
STATUS
00257 6 R/W bit
DI_counterValue high/low word 0016 04:INPUT
REGISTER
30017 12 R 2 words
DI_status 0: OFF, 1: ON 0000 02:INPUT
STATUS
10001 6 R bit
DI-all_statusFromDI-
00
0: OFF, 1: ON 0048 04:INPUT
REGISTER
30049 1 R word
RLY_currentCount high/low word 0096 04:INPUT
REGISTER
30097 12 R 2 words
RLY_currentCountRes
et
1: reset
current count
0048 01:COIL
STATUS
00048 6 R/W bit
RLY_p2pSafeModeFla
gCelar
1: clear safe
mode flag
4128 01:COIL
STATUS
04129 6 R/W bit
RLY_p2pSafeModeFla
g
0: OFF, 1: ON 4112 02:INPUT
STATUS
14113 6 R bit
RLY_p2pStatus 0: OFF, 1: ON 4096 02:INPUT
STATUS
14097 6 R bit
RLY_pulseCount high/low word 0036 03:HOLDI
NG
REGISTER
40037 12 R/W 2 words
RLY_pulseOffWidth unit: 1.5 sec 0068 03:HOLDI
NG
REGISTER
40069 6 R/W word
RLY_pulseOnWidth unit: 1.5 sec 0052 03:HOLDI
NG
REGISTER
40053 6 R/W word
RLY_pulseStatus 0: STOP, 1:
START
0016 01:COIL
STATUS
00017 6 R/W bit
RLY_status 0: OFF, 1: ON 0000 01:COIL
STATUS
00001 6 R/W bit
RLY_TotalCount high/low word 0064 04:INPUT
REGISTER
30065 12 R 2 words
RLY-all_statusFromRL
Y-00
0: OFF, 1: ON 0032 03:HOLDI
NG
REGISTER
40033 1 R/W word

Moxa Technologies ioLogik E1260 Specifications

General

Type	Network transmitter & receiver
Maximum transfer distance	- m
Mean time between failures (MTBF)	660260 h
Certification	UL/cUL Class I Division 2, ATEX Zone 2
Product color	Silver
LED indicators	Yes
Operating temperature (T-T)	-40 - 167 °F
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	2
Input current	0.110 A
AC input voltage	24 V
Operating altitude	0 - 2000 m
Storage temperature (T-T)	-40 - 85 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	84 mm
Width	27.8 mm
Height	124 mm
Weight	200 g
