NPort 5600 Series User’s Manual Web Console Configuration
5-10
Serial Settings
Click Serial Settings, located under Main Menu, to display serial port settings for ports 1 and 2.
NOTE: Once you have completed the hardware installation of NPort 5600, there should be either
16 or 8 ports shown in the figure, depending on the model you installed. The steps for changing
the settings of the other ports are the same as those for Port 1 and Port 2.
To modify serial settings for a particular port, click either Port 1 or Port 2 under Serial Settings,
located under Main Menu on the left side of the browser window
Port alias
Setting Factory Default Necessity
1 to 15 characters
(E.g., PLC-No.1)
None Optional
“Port Alias” is specially designed to allow easy identification of the serial devices which are
connected to NPort’s serial port.
