NPort 5600 Series User’s Manual Introduction
1-3
 Supports SNMP MIB-II for network management
Product Specifications
LAN
Ethernet 10/100 Mbps, RJ45
Protection Built-in 1.5 KV magnetic isolation
Optical Fiber Interface
100BaseFX
NPort 5650-8/16-M-SC NPort 5650-8/16-S-SC
Wavelength
1300 nm 1310 nm
Transmitter power Max
-10 dBm 0 dBm
Transmitter power Min
-20 dBm -5 dBm
Receiver Sensitivity Max
-6 dBm -3 dBm
Receiver Sensitivity Min
-32 dBm -34 dBm
Link Budget
12dB 29 dB
Typical Distance
5KM 40KM
NPort 5610 Serial Interface
Interface RS-232
No. of Ports 16/8
Port Type RJ45 8-pin
Signals TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Serial Line Protection 15 KV ESD for all signals
NPort 5630 Serial Interface
Interface RS-422/485
No. of Ports 16/8
Port Type RJ45 8-pin
Signals RS-422: Tx+, Tx-, Rx+, Rx-, GND
RS-485 (2-wire): Data+, Data-, GND
RS-485 (4-wire): Tx+, Tx-, Rx+, Rx-, GND
Serial Line Protection 15 KV ESD for all signals
RS-485 Data Direction ADDC™ (Automatic Data Direction Control)
NPort 5650 Serial Interface
Interface RS-232/422/485
No. of Ports 16/8
Port Type RJ45 8-pin
Signals RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD,
GND
RS-422: Tx+, Tx-, Rx+, Rx-, GND
RS-485 (2-wire): Data+, Data-, GND
RS-485 (4-wire): Tx+, Tx-, Rx+, Rx-, GND
Serial Line Protection 15 KV ESD for all signals
