NPort 5600 Series User’s Manual Web Console Configuration
5-22
Therefore, you should set Force transmit timeout to be larger than 8.3 ms, so in this case, it must
be greater than or equal to 10 ms.
If the user wants to send the series of characters in the same packet, the serial device attached to
NPort should send that series of characters during a time interval less than the Force Transmit
timeout for NPort, and the total length of data must be less than or equal to NPort’s internal buffer
size. The serial communication buffer size for NPort is 1 KB per port.
Destination IP address 1
Setting Factory Default Necessity
IP address or Domain Address
(E.g., 192.168.1.1)
None Required
Allows NPort to connect actively to the remote host whose address is set by this parameter.
Destination IP address 2/3/4
Setting Factory Default Necessity
IP address or Domain Address
(E.g., 192.168.1.1)
None Optional
Allows NPort to connect actively to the remote host whose address is set by this parameter.
Designated Local Port 1/2/3/4
Setting Factory Default Necessity
TCP Port No.
5011(Port 1) 5012(Port 2)
5013(Port 3) 5014(Port 4)
Required
Connection control
Setting Factory Default Necessity
Startup/None,
Any Character/None,
Any Character/Inactivity Time,
DSR ON/DSR OFF,
DSR ON/None,
DCD ON/DCD OFF,
DCD ON/None
Startup/None Required
The meaning of each of the above settings is given in the table below. In general, both the Connect
condition and Disconnect condition are given.
