PT-7728 User’s Manual Specifications
C-18
0x3200~0x3211 1 word
RSTP Port 1~18 Status
0x0000:Port Disabled
0x0001:Not RSTP Port
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:RSTP Not Enable
0x3300 1 word
TR Master/Slave
0x0000:Slave
0x0001:Master
0xFFFF:Turbo Ring Not Enable
0x3301 1 word
TR 1st Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0x3302 1 word
TR 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0x3303 1 word
TR Coupling
0x0000:Off
0x0001:On
0xFFFF:Turbo Ring Not Enable
0x3304 1 word
TR Coupling Port status
0x0000:Port Disabled
0x0001:Not Coupling Port
0x0002:Link Down
0x0003:Blocked
0x0005:Forwarding
0xFFFF:Turbo Ring Not Enable
0x3305 1 word
TR Coupling Control Port status
0x0000:Port Disabled
0x0001:Not Coupling Port
0x0002:Link Down
0x0003:Blocked
0x0005:Forwarding
0x0006:Inactive
0x0007:Active
0xFFFF:Turbo Ring Not Enable
