PT-7728 User’s Manual Specifications
C-19
0x3500 1 word
TR2 Coupling Mode
0x0000:None
0x0001:Dual Homing
0x0002:Coupling Backup
0x0003:Coupling Primary
0xFFFF:Turbo Ring V2 Not Enable
0x3501 1 word TR2 Coupling Port Primary status
(Using in Dual Homing, Coupling Backup, Coupling
Primary)
0x0000:Port Disabled
0x0001:Not Coupling Port
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Not Enable
0x3502 1 word TR2 Coupling Port Backup status
(Only using in Dual Homing)
0x0000:Port Disabled
0x0001:Not Coupling Port
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Not Enable
0x3600 1 word
TR2 Ring 1 status
0x0000:Healthy
0x0001:Break
0xFFFF:Turbo Ring V2 Not Enable
0x3601 1 word
TR2 Ring 1 Master/Slave
0x0000:Slave
0x0001:Master
0xFFFF:Turbo Ring V2 Ring 1 Not Enable
0x3602 1 word
TR2 Ring 1 1st Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 1 Not Enable
0x3603 1 word
TR2 Ring 1 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 1 Not Enable
