PT-7728 User’s Manual Featured Functions
3-29
NOTE
The user does not need to assign the master to use Turbo Ring or Turbo Ring V2. If no master is
assigned, the Turbo Ring protocol will automatically assign master status to one of the PT series
Ethernet switches in the ring. The master is only used to determine which segment serves as the
backup path.
Ring 1/2—1st Ring Port Status
Ring 1/2—2nd Ring Port Status
The Ports Status indicators show Forwarding for normal transmission, Blocking if this port is
connected to a backup path and the path is blocked, and Link down if there is no connection.
Coupling—Mode
This indicates either None, Dual Homing, or Ring Coupling.
Coupling—Coupling Port status
This indicates either Primary, or Backup.
"Settings" Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring This selects the Turbo Ring protocol.
None
Turbo Ring V2 This selects the Turbo Ring V2 protocol.
Turbo Chain Selects the Turbo Chain protocol.
RSTP (IEEE
802.1w/1D)
This selects the RSTP protocol.
None This disables ring redundancy.
Enable Ring 1
Setting Description Factory Default
Enabled This enables Ring 1.
Not checked
Disabled This disables Ring 1.
Enable Ring 2*
Setting Description Factory Default
Enabled This enables Ring 2.
Not checked
Disabled This disables Ring 2.
*Both Ring 1 and Ring 2 must be enabled when using the dual-ring architecture.
Set as Master
Setting Description Factory Default
Enabled
The PT-7728 is manually selected as the
master.
Not checked
Disabled
The Turbo Ring or Turbo Ring V2 protocol
will automatically select the master.
