DescriptionMSA
ALTAIR 4X
GB
11
2 Description
2.1 Overview
Fig. 1 Device overview
The device monitors gases in ambient air and in the workplace.
It is available with a maximum of three sensors, which can display readings for four
separate gases [one Dual Toxic Sensor provides both CO and H
2
S sensing capa-
bilities in a single sensor].
The alarm levels for the individual gases are factory-set and can be changed
through the Setup Menu. These changes can also be made through MSA Link soft-
1 Communication
8 Display
2 Safe LED [green] and
Fault LED [yellow]
9 Alarm LEDs [4]
3 Sensor Inlets 10 Belt Clip
4 Horn 11 Charging Connection
5
Button 12 Screws [4]
6
Button 13 Charge LED [red/green]
7 ON/OFF Button
9
9
1 2
9
3
4
5
6
7
8
3
11
10
12
13
