DescriptionMSA
ALTAIR 4X
GB
13
LED Definitions
Vibrating Alarm
The device is equipped with a vibrating alarm.
Backlight
The backlight automatically activates when any button is pressed. The backlight re-
mains on for the duration of the user-selected timeout. This on/off duration can be
set through MSA Link software.
Horn
The horn provides an audible alarm.
Operating Beep
This operating beep activates every 30 seconds by momentarily beeping the horn
and flashing the alarm LEDs under the following conditions:
- Operating beep is enabled
- Device is on normal Measure Gases page
- Device is not in battery warning
- Device is not in gas alarm
- Audible and visual options are enabled
LED Description
GREEN The Safe LED flashes once every 15 seconds to notify the user
that the device is on and operating.This option can be turned off
through the MSA Link software.
RED The red LEDs are visual indications of an alarm condition or any
type of error in the device.
YELLOW The yellow LED is a visual indication of an device fault condition.
This LED will be on with the following conditions:
- Device memory error
- Sensor Missing
- Sensor Error
RED/GREEN The Charge LED is a visual indication of charge status.
-RED:
is charging
- GREEN: complete charge
