10.6 COMMAND #143: READ EVENT LOGGING COUNTERS

This command reads five event logging counters.

Request Data Bytes

Byte

Format

Description

None

N/A

Response Data Bytes

Byte

Format

Description

0 – 1

Unsigned-16

2 – 3

Unsigned-16

Alarm Event Counter

4 – 5

Unsigned-16

Fault Event Counter

6 – 7

Unsigned-16

Maintenance Event Counter

8 – 9

Unsigned-16

Calibrate Event Counter

Command-Specific Response Codes

Code

Class

Description

Success

No Command-Specific Errors

1-127

Undefined

10.7 COMMAND #144: CLEAR EVENT LOGGING COUNTERS

This command resets the 4 event logging counters to zero (Alarm, Fault, Calibration, and Maintenance

events).

Request Data Bytes

Byte

Format

Description

None

N/A
