OBSERVER-i HART

12.9 OPERATING MODES

The Observer-i reports dB readings while in RUN mode. Various other modes are used to support the

calibration and setup of the instrument.

12.10 WRITE PROTECTION

The Observer-i does not support any write protection modes.
