OBSERVER-i HART
36
13.3 DEVICE DESCRIPTION LANGUAGE MENU
Observer i
Root Menu
1) Device Setup Menu
2) Calibration Menu
3) Operating Mode
4) Primary Variable (dB)
5) Error Status
6) Loop Current
Diag/Service Menu
1) Power Supply Volts
2) Power Cycle Flag
3) Unit Temperature
4) Peak dB
5) Reset Alarm
6) Operating Mode
7) Alarm Test
8) Acoustic Test
9) Error bits
Configuration Menu
1) Alarm dB Level
2) Alarm Latch
3) Alarm En/De
4) Real Time Clock: Date
5) Real Time Clock: Hour
6) Real Time Clock: Minute
7) Real Time Clock: Second
8) Total in Seconds
9) Alarm Delay Time
10) Current Range
11) Detection Mode
12) Enhance Ao Mode
13) Load Factory Default
Review Menu
1) Model
2) Write Protect
3) Manufacturer
4) Dev ID
5) Tag
6) Long Tag
7) Descriptor
8) Message
9) Date
10) Final Asmbly Num
11) Universal Rev
12) Fld Dev Rev
13) Software Rev
14) Poll Addr
15) Loop Current Mode
16) Num Req Preams
17) Num Resp Preams
Output Condition Menu
1) Analog Output Menu
2) HART Output Menu
Device Information Menu
1) Manufacturer
2) Model
3) Dev ID
4) Config Change Count
5) Tag
6) Long Tag
7) Date
8) Write Protect
9) Descriptor
10) Message
11) Final Asmbly Num
12) Revision #’s Menu
Device Setup Menu
1) Diag/Service Menu
2) Configuration Menu
3) Event Logging Menu
4) Basic Setup Menu
5) Detailed Setup Menu
6) Review Menu
Event Logging Menu
3) Alarm Event Total
4) Alarm Event Log Menu
5) Fault Event Total
6) Fault Event Log Menu
7) Maint Event Total
8) Maint Event menu
9) Cal Event Total
10) Cal Event Log Menu
11) Clear Events
Basic Setup Menu
1) Tag
2) Long Tag
3) Device Information Menu
Detailed Setup Menu
1) Output Condition Menu
2) Device Information Menu
Alarm Event Log Menu
1) Alarm Total
2) Select Log Index
3) Running Time
4) Event Date
5) Event Hour
6) Event Minute
7) Event Sec
8) Alarm Detect by
9? dB inalarm
Fault Log Menu
1) Fault Total
2) Select Log Index
3) Running Time
4) Event Date
5) Event Hour
6) Event Minute
7) Event Sec
8) Event Cause
Cal Log Menu
1) Cal Total
2) Select Log Index
3) Running Time
4) Event Date
5) Event Hour
6) Event Minute
7) Event Sec
8) Event Cause
Revision #’s Menu
1) Universal Rev
2) Fld Dev Rev
3) Software Rev
4) System Firmware Rev
Analog Output Menu
1) Loop Current
2) Loop Current Mode
HART Output Menu
1) Poll Address
2) Num Req Preams
3) Num Resp Preams
Calibration Menu
1) Calibrate
2) Operating Mode
3) Sub Mode
4) Primary Variable (dB)
5) Error Status
Maint Log Menu
1) Maint Total
2) Select Log Index
3) Running Time
4) Event Date
5) Event Hour
6) Event Minute
7) Event Sec
8) Event Cause
Figure 2: Observer-i Device Description Menu
