10.28 COMMAND #201: SET ALARM DELAY TIME

This command sets the alarm delay time.

Request Data Bytes

Byte

Format

Description

Unsigned 8

Alarm delay: Alarm Delay Time = set value x10s.

Ex: Set value =1 mean 1x10s = 10s or set value = 2 means

2x10=20s…

Response Data Bytes

Byte

Format

Description

Unsigned 8

Alarm delay

Command-Specific Response Codes

Code

Class

Description

Success

No Command-Specific Errors

1 - 2

Undefined

Error

Passed Parameter Too Large

Undefined

Error

Too Few Data Bytes Received

6 - 127

Undefined
