(5) Fold the G1 SCBAshoulder strap webbing until
one end can feed between the gap in the Split
D-ring (01).
(6) Work the rest of the G1 SCBAshoulder strap
webbing through the gap. The Split D-ring (01)
should now be fully supported by the specified
stitching loop.
(7) Attach the Retractor (02) to the bottom of
LUNAR:
a) Push and hold in theRetractor Swivel Button
(04).
b) Insert the Swivel End (05) into the bottom of
LUNAR.
(8) Release the Retractor Swivel Button (04) and
ensure that Retractor Assembly is connected
and swiveling freely.
