MSA Ultima X Series User Manual

MSA
Appendix: HART Specific Information
ULTIMA X
®
Series
100
GB
Device Variables Exposed by the ULTIMA Monitor
Dynamic Variable implemented by ULTIMA Monitor
Variable Description Variable Description
Gas Type Sensor gas type
description
Last Cal Date Date sensor was
last calibrated
Alarm Setpoints Gas value at which
an alarm status bit is
set
Auto Zero comp Amount of compen-
sated below zero
drift
Alarm Action increasing or de-
creasing alarm type,
latching or non
latching
Alert option status See next chapter
Alarm Status Indication of alarm
setpoint exceeded
Swap Delay status See next chapter
Input Voltage Device input voltage
level
Min/Max/Avg Minimum, maximum
and avg. value of
PV over time
Sensor Temp
Avg Interval Time interval for
min, max, avg [1, 8
or 24 hr]
Sensor Status Status returned by
sensor
Gas Table Linerisation table
selection
Relay EN/De-eng Relay EN/De-eng
Cal Sig Cal Signal Status
RTC Date Device real time
clock date
RTC Min Device real time
clock minutes
RTC Hrs Device real time
clock hours
Meaning Units
PV Gas Value %, %LEL, PPM
