Appendix: HART Specific Information
ULTIMA X
®
Series
134
GB
13.11 Default Configuration
13.12 Calibration Using a HART® Communicator
Sensor Zero Selection Menu
Select Sensor Calibration from the "Sensor Trim" Menu
Sensor calibration or “trim” functions are available from several locations in the
menu structure. See  Fig. 30 for a view of this selection menu.
Parameter Default Value
Lower Range Value 0
Upper Range Value Sensor dependent
PV Units Sensor dependent
Sensor type various
Number of wires 3
Damping time constant N/A
Fault-indication jumper Sensor dependent
Write-protect mode write enabled
Number of response preambles 5
Alarms Enabled
