Special conditions for safe use:
Some of the flameproof joints have widths that are bigger and gaps that are smaller
than the values required in table 2 of IEC 60079-1. In case of repair or exchange of
parts forming these flameproof parts the widths and the gaps of these joints have
to comply with the values of commercial specification no. 10000012327 signed
04.05.2005 and drawing no. 10000017784 signed 04.05.2005.
Marking: ULTIMA XE MAIN
II 2G Ex d IIC T5
-40°C  Ta  +60°C
if equipped with HART MODULE and XP port
II 2G Ex d [ib] IIC T5
Uo = 6,14 V , Io = 170 mA , Co = 34 uF , Lo = 1,3 mH
Po = 260 mW , Um = 250 VAC
assembled with the following components:
ULTIMA XE ULTIMA X IR
II 2G Ex d IIC T4
-40°C  Ta  +60°C
III 2G Ex d IIC T5
-40°C  Ta  +60°C
only mounted with XE MAIN
ULTIMA XE Ox/Tox ia
II 2G Ex ia IIC T4
-40°C  Ta  +60°C
only together with the ia barrier
EC-Type Examination Certificate: DMT 02 ATEX E 202 X
Quality Assurance Notification: 0080
Year of Manufacture: see Serial Number
Serial Nr.: see Label
EMC Conformance according to the Directive 2004 / 108 / EC
EN 50270:2006 Type 2, EN 61000-6-4:2007
EN 61000-4-6 : Ultima XE MAIN HART MODULE : occasional transmission error
can appear at the 2-wire version. A fault check has to be used at the receiver unit.
MarED Conformance according to the Directive 96/98 EC
SEE BG 213.038, Notified Body number: 0736
LVD Conformance according to the Directive 2006/95/EC
DIN EN 61010-1:2002-08
