33 MTS_OW100_IFU-orthogold100-US-K182682_A
1. In the menu „Language“, select your national language for all displays (menus).
2. Under „Brightness“ select the backlight illumination of the screen.
3. Under „Energy“ select the exposition of the display:
„1-16, „mJ“ or „mJ/mm
2
“. Note: In this menu you can select only with the arrow
buttons.
4. Select the exposition of the time and date. Select the favored exposition with the
arrow buttons. (24h) means 0 – 24 (13, 14 etc.).
5. Display field „Applicator“ shows the connected applicator with his denotation.
„Device-Nr.“ Shows the serial number of the OW100
®
. „Version SW“ shows the
version number of the software. „Pulse“ shows the general number of the pressure
pulses released with this device.
6. Setting of the time and date. Press the field you want to edit and press after the up
and down arrows to select the number.
7. Pressing „back“ gets you back to the operation mode with the accordant display.
8. Pressing „Cartridge“ releases the water cartridge to be able to pull it out.
9. Pressing „Applicator“ decouples the applicator from the OW100
®
. Note: If the
applicator is filled, drain it. Afterwards the motor pushes the connector a little bit out.
After that you can pull the connector out of the socket.
Store packaging
Store the transport box of the OW100
®
in a safe place. To protect the device, it must
only be shipped in this transport box. Also store the packaging of the applicator, to
send it after use, cleaned and disinfected back to MTS.
4 Operating Instructions
Check safety functions
For setting into operation note the following safety instructions:
Unauthorized use!
When the device is not in use, remove the power cable to prevent
unauthorized or non-desired use.
Operation of the OW100
The OW100
must only be operated in horizontal position.
