MTS Systems OrthoGold100 OW100-US User Manual

48 MTS_OW100_IFU-orthogold100-US-K182682_A
Per IEC 63045:2017 Draft
pc [Mpa]: peak-positive acoustic pressure, peak-compressional acoustic pressure
pr [Mpa]: peak-rarefactional (peak-negative) acoustic pressure
PIIT [mJ/mm2]: derived pulse-intensity integral, integrated over total temporal integration limits, total pulse
duration
PIIP [mJ/mm2]: derived pulse-intensity integral, , integrated over positive temporal integration limits,
compressional pulse duration
OW100
®
Generator setting
(Energy)
E b T [mJ]
E 5mm T [mJ]
E b P [mJ ]
E 5mm P [mJ]
1
0.022
0.012
0.019
0.010
2
0.086
0.073
0.076
0.066
3
0.156
0.141
0.139
0.128
4
0.233
0.216
0.208
0.197
5
0.317
0.300
0.285
0.274
6
0.410
0.394
0.369
0.360
7
0.513
0.499
0.463
0.456
8
0.628
0.619
0.567
0.566
9
0.756
0.754
0.684
0.690
10
0.899
0.910
0.815
0.832
11
1.061
1.088
0.964
0.996
12
1.244
1.294
1.132
1.185
13
1.451
1.535
1.324
1.406
14
1.689
1.817
1.545
1.666
15
1.962
2.151
1.800
1.974
16
2.278
2.551
2.096
2.344
Figure 34 Dependence of the acoustic pulse energy on the generator
Per IEC 63045:2017 Draft
EbT [mJ]: Total derived acoustic energy of beam width (-6dB)
E5mmT [mJ]: Total derived acoustic energy of 5mm beam
EbP [mJ]: Positive derived acoustic energy of beam width (-6dB)
E5mmP [mJ]: Positive derived acoustic energy of 5mm beam
Beam sizes (-6dB)
Energy level
Beam volume in Beam width f
x,y
in
mm³
mm
Beam extend f
z
in
mm
1
2890 17.05
38.0
8
1449 11.55
41.5
13
622 8.70
31.4
16
512 9.45
25.4
Figure 35 Dependence of the pressure pulse parameters on the generator
