62 MTS_OW100_IFU-orthogold100-US-K182682_A
Noise emission
Stand-by: 46 dB max.
Treatment: 91.7 dB max.
Mechanical Components
Weight: 18 kg (39.7 lbs)
Size of the basic unit: (H x W x D) 218 x 400 x 459 mm
Water system
Closed system
Content of the water cartridge: 450 ml Water (15.22 fl oz)
Fill time of the reflector: Approx. 25 seconds
Acoustic wave generator
General data:
The coupling to the treatment area happens via water membrane.
Principle: electro hydraulic, spark gap under water caused by discharge of high
voltage condensers.
Acoustic wave release frequency: 0.5 to 8 Hz.
Operation- and display elements
• Operation monitor and touch wheel at the front side of the device
• Power on / off, displayed by control lamp in switch
• Footswitch to release acoustic waves
Supply
Voltage supply: AC 100- 240 V, ± 10 %, 50/60 Hz
Single phase
Class I equipment
Type B
Power consumption: 100V/200VA
240V/200VA
