Connect to a stereo TV
• To determine your best connection, refer to Video Connection Options
Set-top box
These connections serve the
same purpose, use only one
Video in
Sample Stereo TV
TO WALL
(VIDEO IN)
HDMI NETWORK
Pb
Pr
Y
S-VIDEO
OPTICAL
LR
VIDEO OUT AUDIO OUT
TO TV
(VIDEO OUT)
USB
POWER
+12V
DC
CABLE/
ANTENNA IN
INPUT
S-VIDEO
VIDEO
AUDIO LEFT
AUDIO RIGHT
Optical
S/PDIF
RCA-type
Audio
S-Video RCA-type
Video
VIP 1216
VIP 2262
