MTS Systems Ultimate TV - Connect to a Home Theatre Receiver, TV, and VCR

47
Set-top box
Video in
Sample stereo VCR Sample stereo TV
TO WALL
(VIDEO IN)
HDMI NETWORK
Pb
Pr
Y
S-VIDEO
OPTICAL
LR
VIDEO OUT AUDIO OUT
TO TV
(VIDEO OUT)
USB
POWER
+12V
DC
INPUT OUTPUT
VIDEO VIDEO
CABLE/
ANTENNA IN
TO TV
AUDIO AUDIO
LLRR
CABLE/
ANTENNA IN
INPUT
S-VIDEO
VIDEO
AUDIO LEFT
AUDIO RIGHT
Sample Home
Theatre receiver
L VIDEOR S-VIDEO
AUDIO VIDEO
DVD
CABLE TV
VIDEO 2
IN
OUT
VCR
OPTICAL
SPEAKER
CONNECTIONS
TV MONITOR
OUTPUT
VIDEO S-VIDEO
Connect to a home theatre receiver, TV, and VCR
• To determine your best connection, refer to Video Connection Options
• This video connection method does not support HD video. For more information, see Connect an HDTV – Video
Only
RCA-type
Audio
RCA-type
Video
Optical
S/PDIF
