5. Tighten drain screws (2) and (3) with torque wrench to the specified torque.
Name Size Type Lubricant Value/Standard
Screw M26 x 1.5 Tightening torque (Engine oil) 100Nm +10Nm
Filling with new engine oil
1. Open cover on filler neck.
2. Pour oil in at filler neck up to "max." mark at
oil dipstick.
3. Close cap on filler neck.
4. Check engine oil level (→ Page 103).
MS150049/02E 2012-11 | Task Description | 105
TIM-ID: 0000006152 - 008
