Cleaning strainer
1. Shake coarse contamination out of strainer (5).
2. Clean all metallic parts with cleaner (Snow-White 11-0), then rinse with cleaner (Hakupur 312).
3. Use a soft brush to remove stubborn deposits from strainer if required. Ensure that the mesh is not dam‐
aged.
4. Blow out strainer (5) with compressed air from inside.
Checking strainer
Item Findings Action
Strainer Metallic residues • Clean
• Monitor engine operation
• Check strainer daily
• Contact Service.
Strainer Damaged Fit new part
Square-section ring Damaged Fit new part
O-ring Damaged Fit new part
Installing strainer
1. Coat square-section ring (4) on strainer (5) with engine oil and install strainer (5).
2. Insert strainer into housing.
3. Fill housing with new engine oil.
4. Coat O-ring (3) with engine oil and fit in filter housing.
5. Fit cover (2) and secure with screws (1) and washers.
MS150049/02E 2012-11 | Task Description | 109
TIM-ID: 0000036227 - 002
