Flashi
ng
code
PID SID FMI Description Maintenance tasks
62 40 3 Auxiliary output 2, short cir‐
cuit on battery circuit (plus)
A2.
Contact Service.
62 40 4 Auxiliary output 2, open cir‐
cuit A2.
Contact Service.
62 40 7 Auxiliary output 2, mechani‐
cal system does not re‐
spond correctly A2.
Contact Service.
62 53 3 Auxiliary output 5, short cir‐
cuit on battery circuit (plus)
W3.
Contact Service.
62 53 4 Auxiliary output 5, open cir‐
cuit W3.
Contact Service.
62 53 7 Auxiliary output 5, mechani‐
cal system does not re‐
spond correctly W3.
Contact Service.
62 54 3 Auxiliary output 6, short cir‐
cuit on battery circuit (plus)
X3.
Contact Service.
62 54 4 Auxiliary output 6, open cir‐
cuit X3.
Contact Service.
62 54 7 Auxiliary output 6, mechani‐
cal system does not re‐
spond correctly X3.
Contact Service.
62 55 3 Auxiliary output 7, short cir‐
cuit on battery circuit (plus)
Y3.
Contact Service.
62 55 4 Auxiliary output 7, open cir‐
cuit Y3.
Contact Service.
62 55 7 Auxiliary output 7, mechani‐
cal system does not re‐
spond correctly Y3.
Contact Service.
62 56 3 Auxiliary output 8, short cir‐
cuit on battery circuit (plus)
A1.
Contact Service.
62 56 4 Auxiliary output 8, open cir‐
cuit A1.
Contact Service.
62 56 7 Auxiliary output 8, mechani‐
cal system does not re‐
spond correctly A1.
Contact Service.
63 57 0 PWM 1 above normal
range.
Contact Service.
63 57 1 PWM 1 below normal
range.
Contact Service.
63 57 3 PWM 1 short circuit on bat‐
tery circuit (plus).
Contact Service.
63 57 4 PWM 1 open circuit. Contact Service.
