Description
Control terminal
03.06.2014 23
<Sealing> key
• Press and hold down: Call up "Sealing"
menu.
• Press briefly: Call up values for sealing.
• Confirm the configuration code.
• In the MPP process: select the value.
<Gas flushing> key
• In the MPP process: select the function.
In machines with the inert gas option:
• Press and hold down: Call up "Gas flush-
ing" menu.
• Press briefly: Call up values for gas flush-
ing.
<Evacuation> key
• Press and hold down: Call up "Evacuation"
menu.
• Press briefly: Call up values for evacua-
tion.
• Delete configuration code.
• In the MPP process: select the step
<Stop> key
• Skip current machine process and proceed
with the next process.
– Pressing during the evacuation process:
Aborts the evacuation process and re-
sumes the gas flushing process.
– Pressing during the gas flushing proc-
ess: Aborts the gas flushing process
and resumes the sealing process.
– Press during sealing process: Cancel
sealing process and ventilate the
chamber.
• Acknowledge diagnostic message.
• Return from the menu to the status dis-
play.
2.3 Display
The display shows different views with differing information depend-
ing on the machine's phase of operation.
2.3.1 Startup display
The startup screen appears after switching on the machine.
