Description
Technical specifications
30 03.06.2014
Dimensions
Height (a) with closed chamber
lid
370 mm
Width (b) 560 mm
Depth (c) 520 mm
Operating height approx. 256 mm
Effective chamber size (W/H/D) 465 mm/150 mm (optional 220
mm)/355 mm
Sealing length 465 mm
Weight approx. 70 kg
Fig. 18: Dimensions
Installation conditions and ambient conditions
Ambient temperature +2 °C to +40 °C
Storage temperature -25 °C to +80 °C
Relative air humidity during op-
eration or storage of the ma-
chine, max.
90 % non-condensing
Inclination of the machine during
transport, max.
15 °
Minimum room size for machines
with the gas flushing option*
40 m
2
*For safety reasons, a minimum room size is mandatory to prevent
high concentrations of gas.
