Start-up
Setting up the machine and starting it up
34 03.06.2014
¾ Unscrew the screw plug. To do so, turn the screw plug anticlock-
wise.
¾ Fill the vacuum pump with the oil supplied up to the middle of the
oil sight glass.
– The oil level is then approximately in the middle of the oil sight
glass.
max.
min.
¾ Check the oil level on the oil sight glass:
– The oil level should reach the middle of the oil sight glass.
– If oil level is under the MIN mark, add oil.
¾ Turn the screw plug in the fill opening and screw it tight. To do so,
turn the screw plug clockwise.
¾ Wipe off and remove any oil.
¾ Fasten the safety guard.
