Description
Times which have to be set
03.06.2014 27
Time Explanation
Gas flushing
time (option)
The film pouch is filled with inert gas during this
time. The time depends on the input pressure at
the inert gas connection and on the vacuum level
reached in the chamber. If the gas flushing time is
too long, the chamber lid can open or the quality of
the seal seam can be impaired. The pressure dif-
ference becomes too small.
Recommended value: 1 s to 3 s
Sealing time The film pouch is sealed during this time. The seal-
ing time depends on the material and thickness of
the film pouch.
Recommended value: 1.6 s to 1.8 s
2.7 Technical specifications
Power supply connection
Mains voltage 230 V/50 Hz 110 V/60 Hz
Phases 1/N/PE AC
Nominal power 0.3 kW
Nominal current 5 A 9 A
Maximum mains fuse 16 A 20 A
Max. short circuit
current
5 kA
Protection type IP54
Dimensions
Height (a) with open chamber lid 750 mm
Height (a) with closed chamber
lid
310 mm
Width (b) 380 mm
Depth (c) 510 mm
Operating height approx. 290 mm
Effective chamber size (W/H/D) 300 mm/110 mm/295 mm
Sealing length 300 mm
Weight approx. 36 kg
