multivac P200 - Change the Oil in the Vacuum Pump; Drain Oil

Maintenance
Open and close the housing
03.06.2014 67
¾ Tighten the two screws at the rear of the machine. Turn these
screws clockwise.
– The housing is closed and tight.
7.6 Change the oil in the vacuum pump
7.6.1 Drain oil
¾ Allow the machine and vacuum pump to cool down for 1 hour.
¾ Open housing, see Section 7.5 "OPEN AND CLOSE THE HOUSING".
¾ Unscrew the screw plug. Turn the screw plug anticlockwise.
