Maintenance
Change the air de-oiling element
72 03.06.2014
¾ Unscrew the screw plug. Turn the screw plug anticlockwise.
¾ Pull out the air de-oiling element.
¾ Insert a new air de-oiling element with sealing ring.
– The arrow on the air de-oiling element points downwards.
¾ Place the screw plug, together with the spring, onto the air de-
oiling element pipe and tighten it. Turn the screw plug clockwise.
¾ Close housing, see Section 7.5 "OPEN AND CLOSE THE HOUSING".
7.8 Change chamber lid gasket
¾ Open the chamber lid as far as the limit stop and have a second
person hold it.
