Figure 3.3 Rotor box Figur e 3.4 To p box
Figur e 3.5 Fans Figure 3.6 Filter b ox
1
2
3
3
Figur e 3.7
1. Reactivation fan
2. Process fan
3. Filter boxes
190TEN–106 5–J1408 Installation 13
