6.9 Airfilterreplacement
6.9.1 Preparation
1. Set the mode switch to pos ition 0.
2. Wait 60 seconds for the heater to c ool down.
3. Set the main power s wit ch to position 0 and lock the switch.
6.9.2 Reactivationairfilter
1. Open the two latches and lift off the end panel from the filter box, see Figure 6.1 and Figure 6.2 .
2. Pull out the filter fr om the filter box, see Figure 6.3 .
3. Clean the filt er box using a vacuum cleaner.
4. Push the new filter fully into the filte r box. Make sure that the arrow on the filter point s in the same
direction as the air stream, see Figure 6.4 .
5. Install the end panel and close the latches.
Figur e 6.1
Figure 6.2
Figur e 6.3
Figure 6.4
