Tab. 9-23: Diagnostic messages on IO-Link ports according IO-Link integration guide-
line Edition 1
0x10 (16) 0x0020 (32) 0x6230 (25136)
0x6310 (25360)
0x6320 (25376)
0x6330 (25392)
0x6340 (25408)
0x6350 (25424)
0x9811 (38929)
0x9812 (38930)
0x9813 (38931)
0x9814 (38932)
0x9815 (38933)
0x9816 (38934)
0x9817 (38935)
IO-Link master/device: Pa-
rameterization error
Check that the correct IO-Link de-
vice is connected and that only cor-
rect parameters are used.
0x12 (18) 0x0020 (32) 0x5450 (21584)
0x5451 (21585)
0x5452 (21586)
0x5453 (21587)
0x5454 (21588)
0x5455 (21589)
0x5456 (21590)
0x5457 (21591)
0x5458 (21592)
0x5459 (21593)
IO-Link device: A fuse has
blown or is open
Check the IO-Link device.
0x18 (24) 0x0020 (32) 0x5160 (20832) IO-Link device: Outputs
were disabled
Check the devices connected to the
IO-Link device.
0x1A (26) 0x0020 (32) 0x9000 (36864) IO-Link device: Faults with
external resources
Check all resources connected to
the IO-Link device.
Channel
Error Type
Extended Channel
Error Type
IO-Link
event code(s)
Meaning Action
