Start-up
User manual 55530_hdb_en_16 55 / 156
The MVK-MPNIO must be marked in the TIA Portal in the folder structure of
the hardware catalog under
Other field devices | PROFINET IO | IO | Murrelektronik | MVK-MPNIO |
V5.0
 In the hardware catalog, mark the MVK-MPNIO module.
 Drag and drop the entry to an empty area in the "Devices & networks" win-
dow.
Assign the module to a
new IO controller
Fig. 7-2: Assign the module to a new IO controller
 On the module symbol, click Not assigned.
 Select PLC_1.PROFINET-Schnittstelle_1. The module is assigned to an
IO controller.
 For further configuration, double-click the module to select it.
